Open Frame Diesel Generator
>
|
| Place of Origin | Chongqing, China |
| Brand Name | HUAN NENG |
| Certification | CE, ISO 14001, ISO 9001 |
| Model Number | HN13000 |
HN13000 Equal Power Best Luxury Perfect Vertical Air-Cooled Direct-Injection AVR Diesel Generator
Luxury equal power diesel generator
Main selling points:
1. Patented appearance design, elegant appearance, easy to move.
2. Power upgrade, no decompression design to effectively protect the battery and starter motor.
3. Pure copper large motor, sufficient power, high temperature resistance.
4. Waterproof panel, safe and reliable, Easy to use.
5. Increase the battery life of the fuel tank, suitable for various complex environments.
6. Digital voltage regulator, with a wide range of loads and strong load capacity. Vibration bottom plate, thickened frame, truly shock absorption, compression resistance and reinforcement.
Introduce:Our machines are easier to start. And has overload protection, safe operation
Has a solid muffler, which can effectively reduce noise. And the waterproof protection of the OFF/ON switch is an excellent little assistant in your life. With full frame protection, extremely easy to transport and carry, a teen can easily pick it up and carry it away, our machine is compact and lightweight, a portable power source for recreational, emergency and home use, backup Power supply, emergency power supply, all in all it will
come in handy anytime you are out of power, I think you will love it.
The details :
| Unit Type | Luxury Huanneng Power 6500 | Luxury Huanneng Power 8000 | Luxury Huanneng Power 10000 | Luxury Huanneng Power 12000 | Luxury Huanneng Power 13000 | |
| GENERATOR | Excitation method | AVR voltage automatic adjustment | AVR voltage automatic adjustment | AVR voltage automatic adjustment | AVR voltage automatic adjustment | AVR voltage automatic adjustment |
| Rated output power | 5KW | 6KW | 7.5KW | 8KW | 9.0KW | |
| maximum output power | 5.5KW | 6.5KW | 8KW | 9KW | 10.0KW | |
| Rated voltage | 220V | 220V | 220V | 220V/380V | 220V/380V | |
| Insulation class | Class F | Class F | Class F | Class F | Class F | |
| Rated frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | |
| ENGINE | engine model | 188FE | 188FE | 192FE | 195FE | 1100FE |
| Bore*stroke | 88*75mm | 88*75mm | 92*75mm | 95*75mm | 100*75mm | |
| ignition method | compression ignition | compression ignition | compression ignition | compression ignition | compression ignition | |
| engine type | Vertical | single-cylinder | four-stroke | direct injection | air-cooled | |
| Displacement | 420cc | 420cc | 499cc | 520cc | 535cc | |
| Engine fuel consumption per hour | 2L | 2L | 2.3L | 2.5L | 2.5L | |
| fuel type | 0/10/35(on weather) | 0/10/35(on weather) | 0/10/35(on weather) | 0/10/35(on weather) | 0/10/35(on weather) | |
| oil quantity | 1.5L | 1.5L | 1.7L | 1.7L | 1.8L | |
| Start method | Electric start | Electric start | Electric start | Electric start | Electric start | |
| Attachment configuration | control panel | digital display | digital display | digital display | digital display | digital display |
| fuel indicator | Have | Have | Have | Have | Have | |
| oil protector | Have | Have | Have | Have | Have | |
| Caster attachment | Standard | Standard | Standard | Standard | Standard | |
| fuel capacity | 20L | 20L | 20L | 20L | 20L | |
| THE others | noise | 80dBA/7m | 80dBA/7m | 80dBA/7m | 80dBA/7m | 80dBA/7m |
| Continuous working time | 8h | 8h | 8h | 8h | 8h | |
| Machine size L*W*H including wheel height) | 710*560*765 | 710*560*765 | 710*560*765 | 710*560*765 | 710*560*765 | |
| Packaging size L*W*H | 770*770*725 | 770*770*725 | 770*770*725 | 770*770*725 | 770*770*725 | |
| Package | carton | carton | carton | carton | carton | |
| weight | 108kg | 110kg | 115kg | 120kg | 140kg |
|
