ODM OEM 5KW Single-Phase Emergency Facilities Diesel Generator
Single-Cylinder 5KW Diesel Generator
THE ADVANTAGE :
1. Economical and efficient with precise ignition control, intelligent speed adjustment according to load, and more than fuel savings.
2. humanized design concept, integrated panel operation, clear and easy to operate.
3.Use discretionary resources from investors conscientiously and responsibly
ADD: if you want to know more details, please contact us.
| The unit type | BL6500CJ | BL7500CJ | BL10000CJ | |
| Generator | Rated speed | 5KW | 6KW | 7KW |
| Rated frequency | 50hz | 50hz | 50hz | |
| The rated voltage | 230V/400V | 230V/400V | 230V/400V | |
| Power factor | 1.0/0.8 | 1.0/0.8 | 0.8 | |
| Phase velocity | 1/3 phase | 1/3 phase | 1/3 phase | |
| Excitation way | Brushless self-propelled magnetic | Brushless self-propelled magnetic | Brushless self-propelled magnetic | |
| Insulation class | F | F | F | |
| Protection grade | IP23 | IP23 | IP23 | |
| engine | model | 186F | 188F | 192F |
| One hour power | no data | no data | no data | |
| Rated speed | 1500r/min | 1500r/min | 1500r/min | |
| Start the way | DC12V electric motor starts | DC12V electric motor starts | DC12V electric motor starts | |
| In the form of | Straight line, straight spray | Straight line, straight spray | Straight line, straight spray | |
| Air inlet | Naturally aspirated | Naturally aspirated | Naturally aspirated | |
| stroke | 4 | 4 | 4 | |
| Number of cylinders | 1 | 1 | 1 | |
| Cylinder diameter, stroke | 80/90mm | 80/90mm | 100/115mm | |
| Speed way | mechanical | mechanical | mechanical | |
| Stop the direction | mechanical | mechanical | mechanical | |
| The crankshaft to | counterclockwise | counterclockwise | counterclockwise | |
| The oil brand | CD15/40GB11122 | CD15/40GB11122 | CD15/40GB11122 | |
| Fuel consumption rate | 200 g/kw or less. H | 200 g/kw or less. H | 200 g/kw or less. H | |
| Oil consumption rate | 1.5 g/kw or less. H | 1.5 g/kw or less. H | 1.5 g/kw or less. H | |
| Generator sets | Rated power | 5KW | 6KW | 7kw |
| The rated voltage | 230V/400V | 230V/400V | 400V | |
| Maximum current | no data | no data | no data | |
| Rated frequency | 50hz | 50hz | 50hz | |
| Power factor | 1.0/0.8 | 1.0/0.8 | 0.8 | |
| Cooling way | Closed fan water cooled | Closed fan water cooled | Closed fan water cooled | |
| Fuel tank capacity | 1.3 L | 1.5 L | 1.5 L | |
| The noise | 72Dba/7m | 72Dba/7m | 72Dba/7m | |
| The weight of the | 158kg | 160KG | 165KG | |
| Overall dimensions | 1050x610x800mm | 1050x610x800mm | 1050x610x800mm | |
