KN4000 Small Power Open Frame Diesel Generators Single Phase 8kW 5kW

Place of Origin Chongqing, China
Brand Name Kena | Huanneng Power
Certification CE, ISO 14001, ISO 9001, GS, etc.
Model Number KN Series
Minimum Order Quantity 1 Set
Price Nigotiable
Delivery Time 5-7 working days for stock items
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 20,000 sets per month for generators
Product Details
Product Name Power Generator Keywords Generators For Home
High Light

Single Phase Open Frame Diesel Generator


KN 4000 Power Diesel Generators


Open Frame Diesel Generator 5kW

You can tick the products you need and communicate with us in the message board.
Rated Power Phase Starting System
3KW AC Single Phase Recoil
3KW AC Single Phase Electric
5KW AC Single Phase Recoil
5KW AC Single Phase Electric
6.5KW AC Single Phase Recoil
6.5KW AC Single Phase Electric
8KW AC Single Phase Electric
9KW AC Single Phase Electric
10KW AC Single Phase Electric
10KW AC Three Phase Electric
10KW Equal Power Electric
10KW Dual Voltage Electric
Leave a Message
Rated Power Phase Starting System
Product Description

Open Frame Type Diesel Generator

Kena | Huanneng Power

      • Own Factory with R&D, Support OEM&ODM

      • Scientific Management, Sophisticated Technology, Continuous Innovation

      • Premium Quality with CE, ISO, GS Certificates

      • Fast Shipping, 5-7 Days for Stock Items

Product Description


Parameters | Kena • Huanneng Power

Model No. KN3800 KN6500 KN8000 KN10000 KN12000 KN13000
Excitation System AVR Voltage Automatic Adjustment
Rated Power 3KW 5KW 6KW 7.5KW 8KW 9KW
Max. Power 3.5KW 5.5KW 6.5KW 8KW 9KW 10KW
Rated Voltage 220V 220V 220V 220V 220V/380V 220V/380V
Insulation Class F F F F F F
Rated Frequency 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz
Engine Model 178FE 188FE 188FE 192FE 195FE 1100FE
Bore*Stroke 78*62mm 88*75mm 88*75mm 92*75mm 95*75mm 100*75mm
Ignition Method Compression Ignition
Engine Type Vertical, Single Cylinder, 4-Stroke, Air-Cooled, Direct Injection
Engine Speed (rpm) 3000 / 3600 3000 / 3600 3000 / 3600 3000 / 3600 3000 / 3600 3000 / 3600
Displacement 233cc 420cc 420cc 499cc 520cc 610cc
Fuel Consumption 0.7-1L 2L 2L 2.3L 2.5L 2.5L
Fuel Type 0#(Summer)-10#(Winter)-35#(Severe Cold)
Lubrication Capacity 1.1L 1.5L 1.5L 1.7L 1.7L 1.7L
Starting System Recoil Recoil / Electric Recoil / Electric Recoil / Electric Recoil / Electric Recoil / Electric
Control Panel Digital Display Digital Display Digital Display Digital Display Digital Display Digital Display
Fuel Gauge Yes Yes Yes Yes Yes Yes
Oil Protector Yes Yes Yes Yes Yes Yes
Caster Accessories Standard Standard Standard Standard Standard Standard
Fuel Capacity 12.5L 12.5L 12.5L 12.5L 12.5L 12.5L
Noise 70dBA/7m 80dBA/7m 80dBA/7m 80dBA/7m 80dBA/7m 80dBA/7m
Continuous Working Time 8h 8h 8h 8h 8h 8h
Machine Dimensions (mm) 680*460*550 700*480*735 700*480*735 700*480*735 700*480*735 700*480*735
Package Dimensions (mm) 690*480*570 720*505*660 720*505*660 720*505*660 720*505*660 720*505*660
Packing Carton Box Carton Box Carton Box Carton Box Carton Box Carton Box
Weight 70kg 102kg 105kg 110kg 115kg 135kg

product features_01

   We have over 50 models of generators, please feel free to contact us if any interest
