Box Type Silent Generators
>
|
| Place of Origin | Chongqing, China |
| Brand Name | HUAN NENG |
| Certification | CE, ISO 14001, ISO 9001 |
| Model Number | BL31000W |
Rated 23 Max 25kw AVR Long Product Life NOt disrturbing Gasoline generator
Maximum 25KW Silent Gasoline Generator
Guarantee----
1) Guarantee Period: One year or 1000 running hours, depends on whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.
Testing Items of Power Friend Genset:
1) Parts fault testing
2) Fue tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insultion testing
6) Noise testing
7) Loading testing: All qualified generator sets are subjected to a comprehensive performance test which inclides 0% load, 25% load, 50% load, 75% load, 100% load and 110% load and to check, verify that all control systems, alarm and shut-own protection.
The Details
| The unit type | BL18000W | BL25000W | BL31000W | BL36000W | |
| Generator | Rated speed | 15KW | 18KW | 23kw | 28kw |
| Rated frequency | 50hz | 50hz | 50hz | 50hz | |
| The rated voltage | 230V/400V | 230V/400V | 230V/400V | 230V/400V | |
| Power factor | 1.0/0.8 | 1.0/0.8 | 1.0/0.8 | 1.0/0.8 | |
| Phase velocity | 1 phase 2 lines /3 phase 4 lines | 1 phase 2 lines /3 phase 4 lines | 1 phase 2 lines /3 phase 4 lines | 1 phase 2 lines /3 phase 4 lines | |
| Excitation way | Brushless self-propelled magnetic | Brushless self-propelled magnetic | Brushless self-propelled magnetic | Brushless self-propelled magnetic | |
| Insulation class | H | H | H | H | |
| Protection grade | IP23 | IP23 | IP23 | IP23 | |
| engine | model | Inline four-cylinder four-stroke EFI water-cooled electronically controlled gasoline injection | |||
| One hour power | none data | none data | none data | none data | |
| Rated speed | 1500r/min | 1500r/min | 1500r/min | 1500r/min | |
| Start the way | electric start | electric start | electric start | electric start | |
| In the form of | Straight line, straight spray | Straight line, straight spray | Straight line, straight spray | Straight line, straight spray | |
| Air inlet | Naturally aspirated | Naturally aspirated | Naturally aspirated | Naturally aspirated | |
| stroke | 4 | 4 | 4 | 4 | |
| Number of cylinders | 4 | 4 | 4 | 4 | |
| Cylinder diameter, stroke | 65x78mm | 65x78mm | 70x79mm | 70x79mm | |
| Speed way | mechanical | mechanical | mechanical | mechanical | |
| Stop the direction | mechanical | mechanical | mechanical | mechanical | |
| The crankshaft to | counterclockwise | counterclockwise | counterclockwise | counterclockwise | |
| The oil brand | CD15/40GB11122 | CD15/40GB11122 | CD15/40GB11122 | CD15/40GB11122 | |
| Fuel consumption rate | 200 g/kw or less. H | 200 g/kw or less. H | 200 g/kw or less. H | 200 g/kw or less. H | |
| Oil consumption rate | 1.5 g/kw or less. H | 1.5 g/kw or less. H | 1.5 g/kw or less. H | 1.5 g/kw or less. H | |
Generator sets |
Rated power | 15kw | 18kw | 23kw | 28kw |
| The rated voltage | 230V/400V | 230V/400V | 230V/400V | 230V/400V | |
| Maximum current | 69.5 A/each phase 21.7 A | 78 A/each phase 26 A | 100 A/each phase 33.3 A | each phase 40.5 A | |
| Rated frequency | 50hz | 50hz | 50hz | 50hz | |
| Power factor | 1.0/0.8 | 1.0/0.8 | 1.0/0.8 | 1.0/0.8 | |
| Cooling way | Closed fan water cooled | Closed fan water cooled | Closed fan water cooled | Closed fan water cooled | |
| Fuel tank capacity | 25L | 25L | 35L | 35L | |
| The noise | 72Dba/7m | 72Dba/7m | 72Dba/7m | 72Dba/7m | |
| The weight of the | 282kg | 298kg | 324kg | 324kg | |
| Overall dimensions | 1130x720x800mm | 1130x720x800mm | 1300x820x800mm | 1300x820x800mm | |
