Box Type Silent Generators
>
|
| Place of Origin | Chongqing, China |
| Brand Name | HUAN NENG |
| Certification | CE, ISO 14001, ISO 9001 |
| Model Number | YD7600S/SD |
6KW One Cylinder 3 Phases Open-Frame Hand/Electric Start Gasoline Generator
Three-Phases 6KW Gasoline Generator
THE ADVANTAGE :
1. Focus on quality, service and reliability and listen to customers
2. Combining modern technology, quality and aesthetics
3. Continuously improve productivity and review existing workflows
ADD: if you want to know more details, please contact us.
| Unit Type | YD6600E | YD7600E | YD10000E |
| Excitation method | AVR | AVR | AVR |
| maximum output power | 6.0KW | 7.0KW | 8.5KW |
| Rated output power | 5.0KW | 6.5KW | 8.0KW |
| Rated voltage | 230/400V | 230/400V | 230/400V |
| Maximum current | 26.0A | 30.4A | 37.0A |
| Rated frequency | 50hz | 50hz | 50hz |
| Phase | single phase/three phase | single phase/three phase | single phase/three phase |
| power factor cose | 1.0/0.8 | 1.0/0.8 | 1.0/0.8 |
| Insulation class | F | F | F |
| Guide model | 190F | 190F | 190F |
| Bore X Stroke | 90x66mm | 90x66mm | 90x66mm |
| Displacement | 420cc | 420cc | 420cc |
| fuel consumption rate | W374g/KW.h | W374g/KW.h | W374g/KW.h |
| ignition method | transistor electronic ignition | transistor electronic ignition | transistor electronic ignition |
| engine type | Single cylinder, four stroke, forced air cooling, overhead valve | Single cylinder, four stroke, forced air cooling, overhead valve | Single cylinder, four stroke, forced air cooling, overhead valve |
| fuel type | 90# or more gasoline | 90# or more gasoline | 90# or more gasoline |
| oil quantity | 1.1L | 1.1L | 1.1L |
| Start method | Hand start/electric start | Hand start/electric start | Hand start/electric start |
| fuel capacity | 20L | 20L | 20L |
| oil alarm | Have | Have | Have |
| fuel indicator | Have | Have | Have |
| control panel | other | other | other |
| Caster attachment | Standard | Standard | Standard |
| noise | 68Dba/7m | 68Dba/7m | 68Dba/7m |
| Continuous working time | 8h | 8h | 8h |
| Unit size | 1050x590x800mm | 1050x590x800mm | 1050x590x800mm |
| weight | 145kg | 148kg | 156kg |
Contact Us at Any Time
